CB940FB/C is SATA to 3.5” IDE HDD adapter, providing a set of standard 7+15pin SATA connector on the host connection and a set of IDE 40pin 2.54mm pitch connector on the storage device connection. When assembled, it can operate in a variety of operating systems. Such as DOS, Windows 95, 98, XP, 2000, Vista, Win 7, Linux, Unix, and so on.
CB940FB/C adapter allows the installation of 1.8” IDE storage as system disk, boot the operating system directly, without having to install any drivers, but does not affect the execution speed of the storage devices..
1. Fully compliant with SATA revision 2.6
2. ATAT8-APT Specification for Parallel 3.5" drive form factor
Serial ATA Reversion 2.6------------------------------------------------------------------->February 2007
ATA/ATAPI-7------------------------------------------------------------------------------------- >April 2004
The adapter connects to the Host PC in the same way that a 2.5 SFF SSD drive is connected using a SATA cable. It may be used in any application where a SFF SSD drive may be used:
1. desk-top PC
2. Internet Appliances
3. Kiosks
4. Industrial Computers
5. Routers
6. Firewalls
Datasheet Download :
CB940Fx Series.PDF CB940Fx Series(繁體中文).PDF CB940Fx Series(簡體中文).PDF
